CI810B 3BSE042796R1 ABB CompactPCI system interface module Dedicated to the AC 800M series
Product Overview
The ABB CI810B is a CompactPCI system interface module specifically designed for the ABB AC 800M programmable automation controller (PAC). As one of the core components of the AC 800M controller, this module provides a standard CompactPCI interface for communication and data exchange with other modules on the CompactPCI backplane. It supports high-speed data transmission and ensures the efficient operation of the entire system.
Core features
CompactPCI interface: Compliant with PICMG 2.0 standard, supports high-speed data transmission
Dual redundant power input: Ensures that the system can still operate stably in the event of a single power failure
LED status indication: Clearly display the power supply (PWR), operation (RUN), communication (COM) and fault (ERR) status of the module
Plug and play design: Directly installed on the AC 800M CompactPCI control rack, powered and communicating via the backplane bus
Electrical isolation: Electrical isolation is provided between the module and the system backplane to enhance anti-interference capability
Seamless integration of Control Builder M: Easily configure system parameters and data mapping through ABB engineering software
Typical application scenarios
Industrial automation production line: As the core control unit, it manages communication and data exchange among multiple modules
Power monitoring system: It realizes centralized monitoring and control of facilities such as power stations and substations
Water treatment plant: Used for data acquisition and control of equipment such as pumping stations and valve controllers
Building automation: Networked communication with other intelligent devices to achieve intelligent building management
Energy management system: Ensure the stable operation of data acquisition and transmission equipment and optimize energy usage
Technical parameters
Model: CI810B
Order Number: 3BSE042796R1
Product Name: CompactPCI System Interface Module
Applicable systems: ABB AC 800M series controllers (such as PM861, PM862, PM864, etc.)
Interface type: CompactPCI (3U, compliant with PICMG 2.0 standard)
Power input: Dual redundancy +5V DC input
Maximum power consumption: Typical value 10W
Operating temperature: 0°C to +60°C
Storage temperature: -40°C to +85°C
Power supply mode: Supplied by the CompactPCI backplane
