DI802 3BSE022360R1 ABB Ac digital input module AC 800M System 800A
Product Overview
The ABB DI802 is an 8-channel AC digital input module in the AC 800M distributed control system, specifically developed for reliable acquisition of 115 V AC discrete signals. This module is widely used to receive 110-120 V AC field signals from auxiliary contacts of high-voltage equipment, position switches of circuit breakers, alarm relays of transformers, status feedback of motor control centers (MCC), etc., without the need for additional signal conditioning or intermediate relay conversion.
Core features
8-channel independent AC digital input
Input voltage: 115 V AC (Applicable range: 90-140 V AC, 50/60 Hz)
Compatible with active contacts (such as auxiliary contacts of circuit breakers) or passive dry contacts (an external AC query power supply is required)
Input impedance: approximately 10 kΩ (limiting input current and reducing power consumption)
High electrical isolation and safety
Photoelectric isolation is achieved between the channel and the system backplane
Isolation voltage: ≥ 2500V AC (1 minute), in compliance with high-voltage safety standards
Surge resistance: ±4 kV (IEC 61000-4-5)
Anti-interference optimization design
Built-in filter circuit to suppress power grid noise and transient interference
Minimum ON/OFF recognition time: 10 ms (preventing jitter misjudgment)
Technical parameters
High-voltage switchgear monitoring: Collect the open/closed position signals of 110V AC circuit breakers
Transformer protection system: Relay contact feedback for oil temperature overheat, gas alarm, pressure relief, etc
Large Motor Control Center (MCC) : Motor operation status, fault trip, local/remote switching signals
Railway and Rail Transit: Track circuit status, signal feedback (using 110 V AC control circuit)
Renovation of old power plants: Directly connect to the existing 115V AC control circuit to avoid installing intermediate relays
Installation and Usage instructions
Hardware installation
Insert DI802 into the S800 I/O electronic rack (such as TB840A);
Connect to the CI854A (optical fiber) or CI801 (electrical) communication module via the ModuleBus cable;
For dry contact input, an external 115 V AC query power supply (usually from the control transformer) is required.
Software configuration
Add the DI802 device in Control Builder M;
Name each channel (such as "CB_Main_Closed_FB");
Configurable input filtering time (default 10 ms, adjustable) to suppress jitter;
Download the configuration to the AC 800M controller.
Debugging and verification
A constantly lit green LED indicates that the power supply and communication of the module are normal.
View the real-time input status through the System 800xA screen or Control Builder M;
Values can be forced for logical testing (only in debug mode).
Product Images
